Plan a linked lighting layout for exhibition backwalls
The SL-6013-N24L is a 50W linkable LED exhibition floodlight with 24 LEDs, specified 5500 lm ±10% output and a 60° beam. Its AC 100–240V input and pictured three-pin linking arrangement support planning a connected display-light kit. The original installation guide illustrates an N=5 lamp layout.
For stand builders and project procurement teams, order the fixing and lead configuration with the lamps. Share the backwall dimensions, mounting positions, available supply and destination so the permitted linked quantity, cable routing and complete kit can be confirmed before installation.
50W linkable floodlight technical data
| Specification | SL-6013-N24L |
|---|
| Model | SL-6013-N24L |
| Rated power | 50W ±10% |
| Specified light output | 5500 lm ±10% |
| LED quantity / type | 24 / 3535 |
| Beam angle | 60° |
| Fixture input | AC 100–240V |
| Driver working mode listed | Constant current, 1800 mA |
| White-light order ranges | 3000–3500K / 4700–5300K / 6000–7000K |
| Overall height shown | 571.5 mm |
| Head width shown | 219 mm |
| Base dimensions shown | 70 mm front width / 97 mm side dimension |
| Connection | 3-pin plug; linking ports pictured |
| Layout reference | N=5 linked lamps illustrated; exact kit confirmed per order |
| Fitting options | 0526 aluminium clamp; 0527 / 0528 mounting plates |
| Operating temperature | -20°C to +50°C |
Define the connected-lamp kit
The original guide shows a linking lead between two fixture ports and an N=5 arrangement. Specify the proposed lamp quantity and lead route so the permitted configuration can be checked for the actual kit.
Separate the destination power lead from the interconnecting leads in the order list. Confirm connector matching, cable lengths, circuit capacity and the venue's installation requirements before finalising the layout.
Match each fixing to the backwall structure
Select the pictured 0526 aluminium clamp, 0527 plate or 0528 plate according to the fixing profile. Send the frame drawing, thickness and available mounting area to verify the fitting.
Plan room for the 571.5 mm assembly and access to the connections. The installation example places the light above a graphic wall; actual frame suitability depends on the selected hardware and dimensions.
Set the output, finish and white-light version
The 60° beam and specified 5500 lm ±10% output provide the starting information for a display-lighting plan. Test mounting distance, graphic size and lamp spacing in a sample arrangement to assess overlap and coverage.
Black and silver finishes are pictured. Specify the required finish and one of the listed 3000–3500K, 4700–5300K or 6000–7000K white-light order versions with the quotation.
Questions for linked exhibition-light orders
Can I install five lamps in one linked run?
The original N=5 diagram illustrates a five-lamp layout. Send the intended run, supply details and cable requirements to confirm the permitted configuration for the exact kit before ordering.
Are the power and linking leads included?
Specify the destination plug, power lead and each interconnecting lead in the quotation request. Included components and cable lengths are confirmed with the order.
What should a project enquiry contain?
Include SL-6013-N24L, total lamp quantity, proposed linked layout, backwall dimensions, fixing choice, finish, light version and destination. Wholesale orders start from 20 pcs; larger quantities receive lower unit prices.
Wholesale kits, samples and custom requirements
Samples are available for fitting and layout evaluation. Standard lead time is 12–18 days. OEM, ODM and private-label enquiries are supported. Confirm kit contents, carton quantities, protective packing and model-specific market documents with the quote; sample cost, shipping, custom schedules and transit are agreed separately.
